Description
The Cub Lite is ideal for those systems that need high current, but lower storage capacity. This design was built with 4WD’ers, Canopy systems, and small caravans in mind. Once again a compact battery is able to supply a 3000w inverter at full load (250A). It’s built with CALB brand cell and a Heltec Hardware BMS to keep it super simple. The case is a similar size to many of the 100-135Ah batteries, however it packs in 175Ah of capacity.
Special order item: Please note that this product is a special order item, there could be a delay while it is assembled.
What’s the difference compared to the regular Cub?
https://powerpaul.com.au/blog/the-difference-between-lite-and-regular-powerpaul-batteries/
Read more about PowerPaul® battery installation and The Importance of Having your Battery System Professionally Installed. Also see the PowerPaul® Australia Recommended Installers Directory.
PowerPaul’s lithium batteries are proudly Australian-made and owned, delivering reliable performance for your RV, marine, and off-grid power needs.
Specifications
| Rated Capacity | 175Ah |
| BMS | Heltec Hardware BMS |
| Dimensions | 172mm W, 328mm L, 212mm H |
| Weight | Approx 15kg |
| Voltage | 12.8v Nominal |
| Cycle Life | >2000 x 80% cycles (should last more than 10 years) |
| BMS current | 250A discharge, 800A (1 sec). 125A charge, 150A peak. NO direct Alternator Charging. BMS doe not have overcurrent protection. |
| Cell Balancing | 5A Active Balancer installed. |
| Connecting to other batteries | Parallel connection to other identical batteries is allowed (must be same voltage first). Series connection is not allowed. |
| Warranty | 6 Year warranty against manufacturing defects or failure. |
